脉冲阶梯调制高压电源模块输入侧无电压传感器控制技术研究

陈中; 曾鹏; 汪方斌; 缪鑫

doi:10.11884/HPLPB202638.250248

脉冲阶梯调制高压电源模块输入侧无电压传感器控制技术研究

doi: 10.11884/HPLPB202638.250248

陈中^{1, 2,},
曾鹏^{1, 2},
汪方斌^1, ,,
缪鑫^{1, 2}

1.
安徽建筑大学机械与电气工程学院，合肥 230601
2.
安徽建筑大学安徽省工程机械智能制造重点实验室，合肥 230601

基金项目: 安徽省高校省级自然科学研究项目(2024AH050234)

详细信息

作者简介:
陈　中，cz1982@ahjzu.edu.cn

通讯作者:
汪方斌，wangfb@ahjzu.edu.cn。

中图分类号: TM46
计量
- 文章访问数: 25
- HTML全文浏览量: 11
- PDF下载量: 3
- 被引次数: 0
出版历程
- 收稿日期: 2025-08-01
- 修回日期: 2025-11-15
- 录用日期: 2025-11-12
- 网络出版日期: 2025-11-24

Sensorless control technique for the input side of pulse step modulation high-voltage power supply module

Chen Zhong^{1, 2
,},
Zeng Peng^{1, 2},
Wang Fangbin^{1
, ,},
Miao Xin^{1, 2}

1.
School of Mechanical and Electrical Engineering, Anhui Jianzhu University, Hefei 230601, China
2.
Key Laboratory of Intelligent Manufacturing of Construction Machinery, Anhui Jianzhu University, Hefei 230601, China

摘要

摘要: 脉冲阶梯调制（PSM）高压电源广泛应用于超导托卡马克装置的加热系统，采用模块化拓扑结构，通过多个直流电源模块输出叠加形成高压。每个电源模块输入过欠压保护功能，通过在输入电容两端安装电压传感器进行电压检测以实现，所需电压传感器数量庞大，增加了系统检测成本，提高了硬件检测电路的复杂性。介绍了PSM高压电源电路拓扑，详细分析了PSM高压电源的PWM模块循环控制策略，在此基础上提出了一种电源模块输入侧无电压传感器电压检测方法，在PSM高压电源输出侧采用单电压传感器检测电压信号，推导出各电源模块输入侧电压。最后，基于RT-LAB实时仿真平台搭建了仿真模型，实验结果验证了所提出SVM检测方法的有效性。
- 高压电源 /
- 脉冲阶梯调制 /
- 循环控制 /
- 电压检测 /
- 无电压传感器
Abstract: Background
Pulse step modulation (PSM) high-voltage power supply is widely used in the heating systems of the Experimental Advanced Superconducting Tokamak (EAST). This power supply adopts a modular topology, where the high output voltage is generated by superimposing the outputs of multiple independent DC power modules. In conventional designs, input over-voltage and under-voltage protection for each power module is achieved by installing individual voltage sensors across the input capacitors.
Purpose
However, this method requires a large number of voltage sensors, which significantly increases system monitoring costs and complicates the hardware detection circuitry. To address these limitations, this study aims to develop a sensorless voltage measurement (SVM) method capable of estimating the input voltage of each power module using only a single voltage sensor on the output side.
Methods
This paper first introduces the circuit topology of the PSM high-voltage power supply and provides a detailed analysis of its control strategy. Building on this foundation, a novel sensorless voltage detection technique is proposed to estimate the input voltage of each power module. The method utilizes only one voltage sensor installed at the output side of the PSM high-voltage power supply to collect voltage signals, from which the input voltages of individual modules are derived through algorithmic processing.
Results
To validate the proposed method, a model was constructed and tested based on the RT-LAB real-time simulation platform. Experimental results demonstrate that the SVM technique can effectively estimate input voltages, thereby confirming the feasibility of the proposed method.
Conclusions
The study concludes that the SVM method not only reduces the number of required sensors and associated costs but also simplifies the system architecture while maintaining reliable module-level voltage monitoring. The findings provide valuable insights for the design of modular power supplies in large-scale experimental setups and suggest potential applications in other multi-module power electronic systems.
- high-voltage power supply /
- pulse step modulation /
- cyclic control /
- voltage measurement /
- sensorless

HTML全文

图 1 PSM高压电源简化模型

Figure 1. Simplified model of PSM high-voltage power supply

下载: 全尺寸图片幻灯片

图 2 PSM控制结构图

Figure 2. PSM control structure diagram

下载: 全尺寸图片幻灯片

图 3 PWM模块循环

Figure 3. PWM module cycle

下载: 全尺寸图片幻灯片

图 4 常规电压检测方法和SVM方法

Figure 4. Conventional voltage detection methods and SVM methods

下载: 全尺寸图片幻灯片

图 5 SVM电压采集原理

Figure 5. SVM voltage acquisition principle

下载: 全尺寸图片幻灯片

图 6 RT-LAB实验平台

Figure 6. RT-LAB experiment platform

下载: 全尺寸图片幻灯片

图 7 电源模块输入电压

Figure 7. Power module input voltage

下载: 全尺寸图片幻灯片

图 8 电源模块输入电压滤波

Figure 8. Power module input voltage

下载: 全尺寸图片幻灯片

表 1 电源模块电压给定值

Table 1. Power supply module voltage setpoint

No. u_dci voltage/V

1 u_dc1 120

2 u_dc2 112

3 u_dc3 104

4 u_dc4 116

5 u_dc5 108

6 u_dc6 100

下载: 导出CSV

表 2 实验参数

Table 2. Experimental Parameters

number of modules output voltage/V output L/mH output C/μF switching frequency f/kHz

6 620 5 4700 1

下载: 导出CSV
