基于层叠Blumlein的紧凑型全固态直线变压器驱动源

周昊; 杜创洲; 郝宇昕; 邱嵩; 刘庆想

doi:10.11884/HPLPB202638.250453

基于层叠Blumlein的紧凑型全固态直线变压器驱动源

doi: 10.11884/HPLPB202638.250453

西南交通大学物理科学与技术学院，成都 610031

基金项目: 国家自然科学基金面上项目(12575165)；先进激光与高功率微波国家重点实验室基金；四川省自然科学基金面上项目(2022NSFSC0567)

详细信息

作者简介:
周　昊，hao.zhou@my.swjtu.edu.cn

通讯作者:
邱　嵩，song.qiu@swjtu.edu.cn。

中图分类号: TN501
计量
- 文章访问数: 11
- HTML全文浏览量: 5
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2025-12-11
- 修回日期: 2026-01-04
- 录用日期: 2026-01-05
- 网络出版日期: 2026-02-05

Compact All-Solid-State Linear Transformer Driver based on Stacked Blumlein

School of Physics and Technology, Southwest Jiaotong University, Chengdu 610031, China

摘要

摘要: 全固态直线变压器驱动源（Solid-state Linear Transformer Driver, SSLTD）因其模块化、固态化、高可靠性和高重频的优势，已成为脉冲功率技术的重要发展方向。本文提出并研制了一种基于层叠 Blumlein 脉冲产生模块（Stacked Blumlein Pulse Generation Module, SBPGM）的紧凑型全固态直线变压器驱动源，并对其进行了实验验证。每个SBPGM 集成了由高压陶瓷电容与 PCB 分布电感构成的混合型脉冲成形网络、串并联 IGBT 开关阵列及隔离驱动电路。所提出的共地双极性充电SBPGM拓扑消除了单个模块内高压隔离的需求，并实现了驱动绝缘电压的均衡，从而显著提升了系统的紧凑性与可靠性。通过对单个SBPGM的电路仿真研究，验证了其在±5.5 kV充电电压下，输出10.8 kV的倍压输出特性以及理想的高压隔离特性。基于该模块构建的30级SSLTD样机在单级充电电压为 ±5 kV、90 Ω水电阻负载的条件下，获得了总输出电压 279 kV的准方波脉冲，且输出电流峰值为3.1 kA，脉宽(FWHM)为 77ns，上升沿(10%～90%)为 22.4 ns，重频50 Hz，对应峰值功率达0.9 GW。
- 层叠Blumlein /
- 全固态直线变压器 /
- 脉冲功率 /
- IGBT
Abstract: Background
Solid-state linear transformer drivers (SSLTDs), featuring modular architecture, solid-state implementation, high reliability, and high repetition-rate capability, have become an important development direction in pulsed-power technology.
Purpose
This paper proposes and develops a compact SSLTD based on a stacked Blumlein pulse generation module (SBPGM) and experimentally validates its performance.
Methods
The SBPGM integrates a hybrid pulse-forming network composed of high-voltage ceramic capacitors and the distributed inductance of PCB traces, a series--parallel IGBT switching array, and inductively isolated gate-driver circuits. The proposed common-ground bipolar-charging SBPGM topology eliminates the need for high-voltage isolation within an individual module and equalizes the driver insulation voltage stress, thereby significantly improving the compactness and reliability of the overall system.
Results
Circuit simulations of a single SBPGM verify the voltage-doubling behavior and the desired high-voltage isolation characteristics, producing a 10.8 kV output under a charging voltage of 5.5 kV. Based on this module, a 30-stage SSLTD prototype is constructed. With a per-stage charging voltage of 5 kV and a 90 Ωwater load, the prototype generates a 279 kV quasi-square pulse with a peak current of 3.1 kA, a pulse width of 77 ns, and a rise time of 22.4 ns at a repetition rate of 50 Hz, corresponding to a peak power of 0.9 GW.
Conclusions
This SSLTD adopts a modular, scalable architecture. The SBPGMs are electrically and mechanically consistent yet independent, enabling straightforward voltage scaling and simplified implementation. Experiments confirm compact size and high power density, demonstrating the potential of high-repetition-rate all-solid-state pulsed-power sources.
- stacked Blumlein /
- all-solid-state linear transformer driver (SSLTD) /
- pulsed power /
- IGBT

HTML全文

图 1 SBPGM电路与拓扑

Figure 1. Circuit and topology of SBPGM

下载: 全尺寸图片幻灯片

图 2 开关模块原理图

Figure 2. Topology of switching module

下载: 全尺寸图片幻灯片

图 3 SBPGM电路仿真结果

Figure 3. Simulation results of the SBPGM circuit

下载: 全尺寸图片幻灯片

图 4 SBPGM实物与测试波形

Figure 4. SBPGM prototype and experimental results

下载: 全尺寸图片幻灯片

图 5 SSLTD实物图与剖面示意图

Figure 5. Photograph and cross-sectional schematic of the SSLTD

下载: 全尺寸图片幻灯片

图 6 CSSLTD实验测试波形图

Figure 6. experimental waveforms of the CSSLTD

下载: 全尺寸图片幻灯片

参考文献(24)

[1]	江伟华. 高重复频率脉冲功率技术及其应用: (4)半导体开关的特长与局限性[J]. 强激光与粒子束, 2013, 25(3): 537-543 doi: 10.3788/HPLPB20132503.0537 Jiang Weihua. Repetition rate pulsed power technology and its applications: (iv) Advantage and limitation of semiconductor switches[J]. High Power Laser and Particle Beams, 2013, 25(3): 537-543 doi: 10.3788/HPLPB20132503.0537
[2]	陈林, 周良骥, 蒋吉昊, 等. 基于方波LTD的3 MV闪光照相驱动器设计[J]. 强激光与粒子束, 2017, 29: 115001 Chen Lin, Zhou Liangji, Jiang Jihao, et al. Design of 3 MV flash radiographic driver based on square pulse LTD[J]. High Power Laser and Particle Beams, 2017, 29: 115001
[3]	Mazarakis M G, Fowler W E, LeChien K L, et al. High-current linear transformer driver development at sandia national laboratories[J]. IEEE Transactions on Plasma Science, 2010, 38(4): 704-713. doi: 10.1109/TPS.2009.2035318
[4]	邓建军, 王勐, 谢卫平, 等. 面向Z箍缩驱动聚变能源需求的超高功率重复频率驱动器技术[J]. 强激光与粒子束, 2014, 26: 100201 doi: 10.11884/HPLPB201426.100201 Deng Jianjun, Wang Meng, Xie Weiping, et al. Super-power repetitive Z-pinch driver for fusion-fission reactor[J]. High Power Laser and Particle Beams, 2014, 26: 100201 doi: 10.11884/HPLPB201426.100201
[5]	Wang Peng, Xiang Fei, Wang Ganping, et al. Analyzing and improving the output waveform of linear transformer driver cavity[J]. IEEE Transactions on Plasma Science, 2020, 48(11): 3950-3955. doi: 10.1109/TPS.2020.3027884
[6]	Zhou Lin, Li Zhenghong, Wang Zhen, et al. Design of a 5-MA 100-ns linear-transformer-driver accelerator for wire array Z-pinch experiments[J]. Physical Review Accelerators and Beams, 2016, 19: 030401. doi: 10.1103/PhysRevAccelBeams.19.030401
[7]	Chen Lin, Zou Wenkang, Jiang Jihao, et al. First results from a 760-GW linear transformer driver module for Z-pinch research[J]. Matter and Radiation at Extremes, 2021, 6: 045901. doi: 10.1063/5.0003346
[8]	Wei Hao, Qiu Mengtong, Jiang Xiaofeng, et al. A 4-MA linear transformer driver for X-ray generation[J]. Matter and Radiation at Extremes, 2025, 10: 067401. doi: 10.1063/5.0273536
[9]	文振明, 王志国, 吕明辉, 等. 直线变压器驱动源模块中自放电气体火花开关绝缘恢复的研究[J]. 高电压技术, 2025, 51(2): 686-697 doi: 10.13336/j.1003-6520.hve.20240466 Wen Zhenming, Wang Zhiguo, Lyu Minghui, et al. Investigation on insulation recovery of pre-fired gas spark switch in linear transformer driver modules[J]. High Voltage Engineering, 2025, 51(2): 686-697 doi: 10.13336/j.1003-6520.hve.20240466
[10]	Gui Hao, Zhao Zhongyong, Shi Qing, et al. All-solid-state nanosecond pulse power supply based on BLTs and pulse transformer for DBD application[J]. IEEE Transactions on Power Electronics, 2023, 38(8): 10085-10092. doi: 10.1109/TPEL.2023.3274451
[11]	潘昭浩, 张政权, 刘庆想, 等. 高精度多路脉冲延时技术[J]. 强激光与粒子束, 2021, 33: 105001 doi: 10.11884/HPLPB202133.210082 Pan Zhaohao, Zhang Zhengquan, Liu Qingxiang, et al. High-precision multi-channel pulse delay technology[J]. High Power Laser and Particle Beams, 2021, 33: 105001 doi: 10.11884/HPLPB202133.210082
[12]	Wang Yonggang, Xu Lihao, Jiang Song, et al. Solid-state linear transformer driver based on full-bridge bricks[J]. IEEE Transactions on Plasma Science, 2022, 50(5): 1269-1275. doi: 10.1109/TPS.2022.3162956
[13]	Cao Xiangnan, Song Guiying, Chen Yikai, et al. Research on solid-state linear transformer driver power source driving atmospheric pressure plasma jet treatment of epoxy resin[J]. Energies, 2024, 17: 4749. doi: 10.3390/en17184749
[14]	王志国, 孙凤举, 姜晓峰, 等. FLTD大规模气体开关同步触发技术研究[J]. 现代应用物理, 2022, 13: 040407 doi: 10.12061/j.issn.2095-6223.2022.040407 Wang Zhiguo, Sun Fengju, Jiang Xiaofeng, et al. Synchronous trigger technology for large-scale gas switches of FLTD[J]. Modern Applied Physics, 2022, 13: 040407 doi: 10.12061/j.issn.2095-6223.2022.040407
[15]	王杰, 陈林, 冯元伟, 等. 触发隔离元件对多开关触发同步性的影响[J]. 强激光与粒子束, 2025, 37: 035023 Wang Jie, Chen Lin, Feng Yuanwei, et al. Influence of isolation element in trigger circuit on synchronization of multiple switches[J]. High Power Laser and Particle Beams, 2025, 37: 035023
[16]	张天洋, 黄涛, 丛培天, 等. 快脉冲直线变压器初级放电单元开关电容一体化设计[J]. 强激光与粒子束, 2024, 36: 115015 doi: 10.11884/HPLPB202436.240291 Zhang Tianyang, Huang Tao, Cong Peitian, et al. Assembly design of switch and capacitor for fast linear transformer driver primary discharge unit[J]. High Power Laser and Particle Beams, 2024, 36: 115015 doi: 10.11884/HPLPB202436.240291
[17]	Jiang Weihua. Review of solid-state linear transformer driver technology[J]. Matter and Radiation at Extremes, 2018, 3(4): 159-164. doi: 10.1016/j.mre.2018.02.001
[18]	Zhang Haoran, Shu Ting, Liu Shifei, et al. A compact modular 5 GW pulse PFN-Marx generator for driving HPM source[J]. Electronics, 2021, 10: 545. doi: 10.3390/electronics10050545
[19]	Huang Liyang, Xiang Zhongwu, Deng Bingfang, et al. A compact gigawatt pulsed power generator for high-power microwave application[J]. IEEE Transactions on Electron Devices, 2023, 70(7): 3885-3891. doi: 10.1109/TED.2023.3279811
[20]	Gao Jingming, Li Song, Yang Hanwu, et al. A novel compact solid-state high power pulse generator based on magnetic switch and square waveform pulse transformer[J]. Review of Scientific Instruments, 2023, 94: 014707. doi: 10.1063/5.0110453
[21]	Wang Limin, Zhang Zhengquan, Liu Qingxiang, et al. Development of a 500-kV all solid-state linear transformer driver[J]. IEEE Transactions on Plasma Science, 2021, 49(6): 1915-1919. doi: 10.1109/TPS.2021.3077610
[22]	Hao Yuxin, Zhou Hao, Qiu Song, et al. Customized output voltage stacked Blumlein pulse generator: its high-voltage isolation and coupling elimination[J]. IEEE Transactions on Power Electronics, 2025, 40(7): 9418-9428. doi: 10.1109/TPEL.2025.3545674
[23]	王利民. 固态直线变压器驱动源的探索研究[D]. 成都: 西南交通大学, 2022 Wang Limin. Study on solid-state linear transformer driver[D]. Chengdu: Southwest Jiaotong University, 2022
[24]	郝宇昕, 周昊, 邱嵩, 等. 集成隔离30 kV全固态层叠Blumlein脉冲发生器[J]. 强激光与粒子束, 2024, 36: 115021 doi: 10.11884/HPLPB202436.240234 Hao Yuxin, Zhou Hao, Qiu Song, et al. Integrated voltage-isolated 30 kV all solid-state stacked Blumlein pulse generator[J]. High Power Laser and Particle Beams, 2024, 36: 115021 doi: 10.11884/HPLPB202436.240234
