Numerical simulation method for thermal blooming effect in atmospheric propagation of supercontinuum laser
-
摘要: 超连续谱激光因其宽光谱特性在光电对抗中具有较大应用潜力。本文基于光波传播的Maxwell波动方程和大气热吸收流体运动方程，提出了一种超连续谱激光大气传输热晕效应的数值仿真方法，该方法考虑了超连续谱激光不同波长成分大气吸收和衰减效应的差异性，结合超连续谱激光光源的光谱分布和大气辐射传输原理，构建了可表征各波长成分大气吸收累积热效应的热晕相位屏，并采用多层相位屏傅里叶变换和多波长非相干叠加的求解方法，建立了超连续谱大气传输热晕效应的数值仿真模型。通过对比已有单波长激光大气传输热晕效应的理论结果，验证了仿真模型的可靠性。基于数值仿真模型，对不同发射功率的超连续谱激光大气传输热晕效应进行了初步仿真，计算了超连续谱激光大气传输的典型到靶光强分布、质心偏移量、Strehl比和能量分布曲线等参数，得出超连续谱激光特殊光强分布以及一些光束特性。本文提出的数值方法为高功率超连续谱激光大气传输热晕效应的研究提供了研究基础。Abstract:
Background The propagation of high-power lasers through the atmosphere is subject to thermal blooming effects, which arise from wavelength-dependent atmospheric absorption and subsequent refractive index perturbations. Supercontinuum lasers, characterized by broad spectral bandwidths, introduce additional complexity due to differential absorption and attenuation across their spectral components.Purpose This study aims to develop a numerical simulation method for the thermal blooming effect during atmospheric propagation of supercontinuum lasers, with particular focus on accounting for the differential atmospheric absorption and attenuation across various wavelengths within the supercontinuum spectrum.Methods Based on Maxwell’s wave equations for light propagation and the fluid dynamics equations for atmospheric thermal absorption, a numerical simulation model was established using a multi-layer phase screen Fourier transform method and a multi-wavelength incoherent superposition approach. A thermal blooming phase screen was constructed by integrating the spectral distribution of the supercontinuum laser source with principles of atmospheric radiative transfer to characterize the cumulative thermal effects from atmospheric absorption at each wavelength component. The reliability of the simulation model was verified by comparing its results with existing theoretical outcomes for single-wavelength laser atmospheric thermal blooming.Results Using the proposed numerical simulation model, preliminary simulations were conducted on the atmospheric thermal blooming effects of supercontinuum lasers at different emission powers. Key parameters such as typical on-target intensity distribution, centroid offset, Strehl ratio, and energy distribution curves for atmospheric propagation were calculated. The results reveal the unique intensity distribution and certain beam characteristics of the supercontinuum laser.Conclusions The numerical method proposed in this paper provides a foundational research tool for studying the thermal blooming effects in high-power supercontinuum laser atmospheric propagation. -
图 1 超连续谱激光大气传输热晕效应仿真流程图
Figure 1. Simulation flowchart of thermal blooming effect in atmospheric propagation of supercontinuum laser
图 3 超连续谱激光SC在400～
2500 nm范围内的归一化光谱分布Figure 3. Normalized spectral distribution of the supercontinuum (SC) laser within the 400～
2500 nm range
图 4 400～
2500 nm超连续谱激光水平传输1～50 km的大气总透过率分布Figure 4. Total atmospheric transmittance distribution for a 400-
2500 nm supercontinuum laser over a 1～50 km horizontal propagation path
图 5 不同波长与功率下的激光光斑分布：(a)-(c)
3000 W功率，波长400 nm、1064 nm、2500 nm；(d)-(f)5000 W功率，波长400 nm、1064 nm、2500 nm；(g)-(i)10000 W功率，波长400 nm、1064 nm、2500 nmFigure 5. Laser spots at wavelengths of 400,
1064 , and2500 nm under powers of3000 ,5000 , and10000 W
图 6 (a),(b),(c)
3000 W,5000 W,10000 W超连续谱激光光斑分布Figure 6. Laser spot distribution of
3000 W,5000 W, and10000 W supercontinuum lasers
图 7 不同功率条件下，单波长激光(
1064 nm)的远场光斑分布(a)3000 W; (b)5000 W; (c)10000 WFigure 7. Far-field spot distributions of single-wavelength laser (
1064 nm) under different power conditions (a)3000 W; (b)5000 W; (c)10000 W
图 8 5000W各波长激光能量分布曲线图
Figure 8. Energy distribution curve of
5000 W laser at various wavelengths表 1 CART仿真参数表
Table 1. CART simulation parameters
parameter name value parameter name value atmospheric model mid-latitude summer aerosol type rural horizontal visibility range 1～50 km observation height 1 km horizontal transmission distance 1 km spectral sampling interval 1 nm
下载: 导出CSV
表 2 仿真参数表
Table 2. Simulation parameters
parameter name value parameter name value emitter aperture 40 mm wind speed 5 m/s light field sampling points 512×512
下载: 导出CSV
表 3 质心偏移量
Table 3. Centroid displacement
laser power/W centroid displacement SC laser/nm 400 nm 1064 nm2500 nm3000 3.592 3.532 3.348 3.515 5000 5.496 5.469 5.040 5.463 10000 8.891 8.336 8.099 8.208
下载: 导出CSV
表 4 Strehl比
Table 4. Strehl ratio
laser power/W Strehl ratio SC laser/nm 400 nm 1064 nm2500 nm3000 0.0800 0.3513 0.2828 0.1849 5000 0.0096 0.1579 0.2008 0.0647 10000 0.0061 0.0736 0.1023 0.0421
下载: 导出CSV
-
[1] 侯静, 陈胜平, 陈子伦, 等. 高功率超连续谱光源研究进展与关键技术分析[J]. 激光与光电子学进展, 2013, 50: 080010 doi: 10.3788/LOP50.080010Hou Jing, Chen Shengping, Chen Zilun, et al. Recent developments and key technology analysis of high power supercontinuum source[J]. Laser & Optoelectronics Progress, 2013, 50: 080010 doi: 10.3788/LOP50.080010 [2] 谌鸿伟. 基于光子晶体光纤的高功率全光纤超连续谱光源[D]. 长沙: 国防科学技术大学, 2014: 5-8Chen Hongwei. High-power all-fiber supercontinuum generation from photonic crystal fiber[D]. Changsha: National University of Defense Technology, 2014: 5-8 [3] 陈胜平, 谌鸿伟, 侯静, 等. 30W皮秒脉冲光纤激光器及高功率超连续谱的产生[J]. 中国激光, 2010, 37(8): 1943-1949 doi: 10.3788/CJL20103708.1943Chen Shengping, Chen Hongwei, Hou Jing, et al. 30W picosecond pulsed fiber laser and high power supercontinuum generation[J]. Chinese Journal of Lasers, 2010, 37(8): 1943-1949 doi: 10.3788/CJL20103708.1943 [4] Zhang Ke, Sun Quan, Chu Xiuxiang. Analytical study on the steady-state thermal blooming of incoherent combining beam[J]. Atmosphere, 2022, 13: 1678. doi: 10.3390/atmos13101678 [5] Gebhardt F G. High power laser propagation[J]. Applied Optics, 1976, 15(6): 1479-1493. doi: 10.1364/AO.15.001479 [6] 周焕然, 朱辰, 王超, 等. 关于激光大气传输的仿真研究进展[J]. 激光与红外, 2025, 55(2): 163-169 doi: 10.3969/j.issn.1001-5078.2025.02.001Zhou Huanran, Zhu Chen, Wang Chao, et al. Progress in simulation research on laser atmospheric transmission[J]. Laser & Infrared, 2025, 55(2): 163-169 doi: 10.3969/j.issn.1001-5078.2025.02.001 [7] 蔡邦维, 黄文龙, 吕百达, 等. 强激光大气传输热晕方程的积分表示[J]. 激光技术, 1996, 20(4): 240-245Cai Bangwei, Huang Wenlong, Lü Baida, et al. An integral expression for thermal blooming equation of high-power laser propagation through atmosphere[J]. Laser Technology, 1996, 20(4): 240-245 [8] 江丽, 宋锐, 侯静, 等. 高功率可见光至近红外波段超连续谱光源研究进展[J]. 光学学报, 2023, 43: 1719001 doi: 10.3788/AOS230763Jiang Li, Song Rui, Hou Jing, et al. Research progress of high-power visible to near-infrared supercontinuum source[J]. Acta Optica Sinica, 2023, 43: 1719001 doi: 10.3788/AOS230763 [9] 王莹莹, 张楠, 张培晴, 等. 全正色散双包层拉锥Ge-As-Se-Te光纤中的宽带相干超连续谱产生[J]. 中国激光, 2022, 49: 0101010 doi: 10.3788/CJL202249.0101010Wang Yingying, Zhang Nan, Zhang Peiqing, et al. Broadband and coherent supercontinuum generation in all-normal-dispersion double-clad Ge-As-Se-Te fiber taper[J]. Chinese Journal of Lasers, 2022, 49: 0101010 doi: 10.3788/CJL202249.0101010 [10] 吴书云, 李新阳, 罗曦. 不同强度分布激光水平传输稳态热晕效应的数值模拟[J]. 光电工程, 2018, 45: 170620 doi: 10.12086/oee.2018.170620Wu Shuyun, Li Xinyang, Luo Xi. Numerical simulation of horizontal propagation steady-state thermal blooming effect on laser beam with different intensity distribution[J]. Opto-Electronic Engineering, 2018, 45: 170620 doi: 10.12086/oee.2018.170620 [11] 李雅倩, 朱文越, 钱仙妹. 超连续谱激光在湍流大气中传输特性的数值仿真研究[J]. 光子学报, 2019, 48: 1001002 doi: 10.3788/gzxb20194810.1001002Li Yaqian, Zhu Wenyue, Qian Xianmei. Numerical simulation of propagation performance of super-continuum laser in turbulent atmosphere[J]. Acta Photonica Sinica, 2019, 48: 1001002 doi: 10.3788/gzxb20194810.1001002 [12] 张琪. 高功率激光大气热晕效应模拟及相位补偿研究[D]. 无锡: 江南大学, 2024: 26-40Zhang Qi. Simulation and phase compensation research on atmospheric thermal blooming effect of high-power laser[D]. Wuxi: Jiangnan University, 2024: 26-40 [13] 饶瑞中. 现代大气光学[M]. 北京: 科学出版社, 2012: 481-498Rao Ruizhong. Modern atmospheric optics[M]. Beijing: Science Press, 2012: 481-498 [14] 杨云涛, 龚艳春, 冷坤, 等. 一种基于复数相位屏的强激光大气传输仿真方案[J]. 激光与红外, 2021, 51(4): 415-420 doi: 10.3969/j.issn.1001-5078.2021.04.003Yang Yuntao, Gong Yanchun, Leng Kun, et al. A simulation scheme of high power laser atmospheric transmission based on complex phase screen[J]. Laser & Infrared, 2021, 51(4): 415-420 doi: 10.3969/j.issn.1001-5078.2021.04.003 [15] 李杨, 刘磊, 王钢, 等. 高能激光短距离传输光束质量测量仿真与实验研究[J]. 红外与激光工程, 2024, 53: 202402 doi: 10.3788/IRLA20240249Li Yang, Liu Lei, Wang Gang, et al. Simulation and experimental study of beam quality measurement for short distance transmission of high power laser[J]. Infrared and Laser Engineering, 2024, 53: 202402 doi: 10.3788/IRLA20240249 [16] Zhang Qi, Hu Qili, Wang Hongyan, et al. High-precision calculation and experiments on the thermal blooming of high-energy lasers[J]. Optics Express, 2023, 31(16): 25900-25914. doi: 10.1364/OE.497914 [17] 魏合理, 戴聪明, 武鹏飞, 等. 更新升级的通用大气辐射传输软件CART2(特约)[J]. 红外与激光工程, 2020, 49: 202010 doi: 10.3788/IRLA20201024Wei Heli, Dai Congming, Wu Pengfei, et al. An upgraded combined atmospheric radiative transfer CART2 (Invited)[J]. Infrared and Laser Engineering, 2020, 49: 202010 doi: 10.3788/IRLA20201024 [18] 钱仙妹, 朱文越, 黄印博, 等. 激光湍流大气传输数值模拟中计算参量的选取[J]. 光子学报, 2008, 37(10): 1986-1991Qian Xianmei, Zhu Wenyue, Huang Yinbo, et al. Selection of computing parameters in numerical simulation of laser beam propagation in turbulent atmosphere[J]. Acta Photonica Sinica, 2008, 37(10): 1986-1991 [19] 黄印博, 王英俭. 热晕效应数值模拟中对计算参数的选取[J]. 强激光与粒子束, 2005, 17(1): 1-4Huang Yinbo, Wang Yingjian. Choosing computing parameters in the numerical simulation of thermal blooming effects[J]. High Power Laser and Particle Beams, 2005, 17(1): 1-4 [20] 任宏岩, 李刚, 沈洪斌, 等. 稳态热晕对激光束大气传输特性的影响[J]. 激光与红外, 2010, 40(1): 14-17 doi: 10.3969/j.issn.1001-5078.2010.01.003Ren Hongyan, Li Gang, Shen Hongbin, et al. Influence of steady-state thermal blooming for laser beam under atmospheric transmission[J]. Laser & Infrared, 2010, 40(1): 14-17 doi: 10.3969/j.issn.1001-5078.2010.01.003 -
