纳秒上升沿同轴型固态Marx发生器的研究与设计

王永刚; 庞博宇; 李孜; 姜松

doi:10.11884/HPLPB202638.260001

纳秒上升沿同轴型固态Marx发生器的研究与设计

doi: 10.11884/HPLPB202638.260001

上海理工大学机械工程学院，上海 210093

基金项目: 国家自然科学基金项目(12305282)

详细信息

作者简介:
王永刚，fduwangyg@163.com

中图分类号: TN78;TN386.1
计量
- 文章访问数: 21
- HTML全文浏览量: 9
- PDF下载量: 5
- 被引次数: 0
出版历程
- 收稿日期: 2026-01-04
- 修回日期: 2026-03-20
- 录用日期: 2026-03-17
- 网络出版日期: 2026-04-18

Design of a coaxial fast rising edge solid-state Marx generator

英文作者,

英文单位

摘要

摘要: 为满足纳秒级快前沿脉冲需求，针对传统固态Marx发生器性能不足的问题，通过在LTspice中对固态Marx发生器电路中各项参数进行分析仿真，确定各项寄生参数对电路上升沿的影响，选用低寄生电感与寄生电容并带有开尔文源极的TO-263-7封装的半导体开关，同时采用单级双路对称并联开关实现均流设计优化了输出脉冲的上升时间，并使用同轴输出结构优化波形的同时便于级联。搭建了一台15级同轴型固态Marx样机，通过对200 Ω负载在10 kV电压下进行实验输出，获得了电流0～50 A、上升时间低于8 ns、脉宽200 ns～5 μs，频率0～10 kHz可调的快前沿高压脉冲，实验结果表明，所设计的装置在上升时间、脉冲幅值和重复频率等关键指标上表现良好，具有较高的综合性能。
- 固态Marx发生器 /
- 快上升沿 /
- 寄生参数 /
- 同轴线 /
- 纳秒脉冲
Abstract: Background
With the growing demand for fast-rising high-voltage pulses in industrial, medical, and plasma-related applications, solid-state Marx generators are increasingly used as pulse sources. However, the limited switching performance of semiconductor devices and constraints of circuit topology pose significant challenges for the design of solid-state Marx generators capable of producing very steep rising time.
Purpose
This study investigates the factors that determine the rise time of solid-state Marx generators and, on this basis, develops a generator that meets the performance requirements for fast-rising pulses.
Methods
A discharge-circuit model of a semiconductor-switched solid-state Marx generator was established, and simulations of parasitic elements were carried out in LTspice to identify their influence on the pulse rise time. In addition, the characteristic impedance of a coaxial output structure was incorporated into the simulations. Guided by these results, a solid-state Marx generator using dual parallel switching paths and a coaxial output structure was designed.
Results
Simulation results indicate that the series parasitic inductance of the circuit, the gate-drive resistance, and the Miller capacitance of the switches have the greatest impact on the rise time. By selecting appropriate MOSFETs and choosing a coaxial inner conductor with a characteristic impedance of 177.4 Ω for a 200 Ω load, a coaxial solid-state Marx generator was realized that delivers 10 kV/50 A pulses with a measured rise time of 7.6 ns.
Conclusions
Based on this analysis and design, a high-performance high-voltage pulse generator has been developed. The results provide a useful reference for further shortening the rise time of solid-state Marx generators, broadening their application range, and promoting their use as alternatives to conventional gas-switch Marx generators.
- solid-state marx generator /
- fast rising time /
- parasitic parameters /
- coaxial line /
- nanosecond pulse

HTML全文

图 1 固态Marx放电回路等效模型

Figure 1. Equivalent model of solid-state Marx discharge circuit

下载: 全尺寸图片幻灯片

图 2 影响上升沿较大的寄生参数

Figure 2. Parasitic parameters significantly affecting the rising edge

下载: 全尺寸图片幻灯片

图 3 带有开尔文源极的MOSFET的影响

Figure 3. Influence of MOSFET with Kelvin Source

下载: 全尺寸图片幻灯片

图 4 主电路及辅助电路拓扑

Figure 4. Main circuit and auxiliary circuit topology

下载: 全尺寸图片幻灯片

图 5 驱动电路原理图

Figure 5. Schematic diagram of the driver circuit

下载: 全尺寸图片幻灯片

图 6 同轴结构输出示意图

Figure 6. Output of coaxial structure

下载: 全尺寸图片幻灯片

图 7 放电回路等效阻抗

Figure 7. Equivalent impedance of discharge circuit

下载: 全尺寸图片幻灯片

图 8 开关上升时间不同时，阻抗不匹配对波形的影响

Figure 8. Impact of impedance mismatch on waveforms under varying switching rise times

下载: 全尺寸图片幻灯片

图 9 不同$ {Z}_{0} $的输出仿真

Figure 9. Output Simulation for Different $ {Z}_{0} $

下载: 全尺寸图片幻灯片

图 10 单级电路板示意图

Figure 10. Single-stage PCB schematic diagram

下载: 全尺寸图片幻灯片

图 11 电路级联结构示意图

Figure 11. Circuit Cascade Structure

下载: 全尺寸图片幻灯片

图 12 15级Marx级联实物图

Figure 12. Module of 15-stage Marx cascade

下载: 全尺寸图片幻灯片

图 13 实验平台

Figure 13. Experimental platform

下载: 全尺寸图片幻灯片

图 14 单级Marx输出波形

Figure 14. Single-stage Marx output waveform

下载: 全尺寸图片幻灯片

图 15 有无内导体输出对比

Figure 15. Comparison of output with internal conductor added

下载: 全尺寸图片幻灯片

图 16 加装内导体输出上升沿对比

Figure 16. Comparison of rising edge of output with internal conductor added

下载: 全尺寸图片幻灯片

图 17 5 kΩ负载下10 kHz频率输出

Figure 17. Output at 10 kHz frequency under 5 kΩ load

下载: 全尺寸图片幻灯片

图 18 2 kΩ负载下放电脉宽调整

Figure 18. Adjustment of discharge pulse width under 2 kΩ load

下载: 全尺寸图片幻灯片

表 1 MOSFET参数对比

Table 1. Comparison of MOSFET parameters

MOSFET model	manufacturing Process	V_DSmax/V	I_D(pulse)/A	Qg/nC	package
C2M0080120D	SiC	1200	80	71	TO-247-3
C2M0045170P	SiC	1700	160	204	TO-247-4
IMBG120R140M1H	SiC	1200	47	13.4	TO-263-7
1Q12160D7Z	SiC	1200	47.5	43	TO-263-7
GS66508B	GaN	650	60	6.1	DFN-4

下载: 导出CSV
