105/140 GHz双频兆瓦级回旋管的设计与实验进展

胡林林 孙迪敏 黄麒力 卓婷婷 龚胜刚 胡鹏 蒋艺 马国武 陈洪斌 马弘舸

胡林林, 孙迪敏, 黄麒力, 等. 105/140 GHz双频兆瓦级回旋管的设计与实验进展[J]. 强激光与粒子束, 2023, 35: 083004. doi: 10.11884/HPLPB202335.230114
引用本文: 胡林林, 孙迪敏, 黄麒力, 等. 105/140 GHz双频兆瓦级回旋管的设计与实验进展[J]. 强激光与粒子束, 2023, 35: 083004. doi: 10.11884/HPLPB202335.230114
Hu Linlin, Sun Dimin, Huang Qili, et al. Design and experimental progress of a 105/140 GHz dual-frequency MW-level gyrotron[J]. High Power Laser and Particle Beams, 2023, 35: 083004. doi: 10.11884/HPLPB202335.230114
Citation: Hu Linlin, Sun Dimin, Huang Qili, et al. Design and experimental progress of a 105/140 GHz dual-frequency MW-level gyrotron[J]. High Power Laser and Particle Beams, 2023, 35: 083004. doi: 10.11884/HPLPB202335.230114

105/140 GHz双频兆瓦级回旋管的设计与实验进展

doi: 10.11884/HPLPB202335.230114
基金项目: 国家自然科学面上基金项目(12175217);技术基础科研项目(JSJL2021212B003)
详细信息
    作者简介:

    胡林林,hulinlin2016@163.com

    通讯作者:

    黄麒力,huangqilicaep@163.com

    马国武,huter_ma@126.com

  • 中图分类号: TN129

Design and experimental progress of a 105/140 GHz dual-frequency MW-level gyrotron

  • 摘要: 介绍了105/140 GHz双频兆瓦级回旋管的设计和最新实验进展。该回旋管的谐振腔、准光模式变换器、BN输出窗采用了双频共用的设计,电子枪采用了双频复用的双阳极磁控注入枪,收集极采用单级降压。在现有实验室电网功率容量有限的情况下,进行脉冲调试,得到的实验结果为:在重频1 Hz、ms连续短脉冲条件下,在105 GHz点和140 GHz点脉冲功率分别达到710 kW和1.057 MW,脉宽0.7 ms,对应总效率分别为34%和49%。在105 GHz点通过脉宽延展和老炼,进一步得到300 kW/2 s和400 kW/1 s的秒级脉宽实验结果,BN窗片的温度在两种状态下温度分别达到606 ℃和503 ℃,波束频率单一,没有杂模。实验基本上验证了该器件的物理设计。
  • 图  1  105/140 GHz设计模型及组成图

    Figure  1.  Design model and components of the 105/140 GHz MW gyrotron

    图  2  105/140 GHz MW回旋管照片和实验装置

    Figure  2.  Photographs of the 105/140 GHz MW gyrotron and experimental setup

    图  3  5 ms单次短脉冲作用下在窗表面热敏纸上形成的束斑图

    Figure  3.  Thermal paper’s burned patterns of RF beams at the window aperture at 105 GHz and at 140 GHz obtained by a 5 ms short pulse

    图  4  140 GHz/1 MW连续脉冲测试时的波形

    Figure  4.  Pulse test waveforms of output with the 140 GHz/1 MW continuous short-pulse operation

    图  5  105 GHz点脉宽扩展测试波形(105 GHz /400 kW/1 s)

    Figure  5.  Results of pulse extension test of output with 105 GHz /400 kW/1 s

    图  6  105 GHz 点脉宽扩展测试波形(105 GHz /300 kW/2 s)

    Figure  6.  Results of pulse extension test of output with 105 GHz /300 kW/2 s

    图  7  脉宽扩展测试时得到的窗片最高温度时的红外成像图

    Figure  7.  Infrared images at the highest temperature of windows during pulse extension tests

    图  8  105 GHz/300 kW/2 s长脉冲运行时波束混频信号频谱截图

    Figure  8.  Spectrum of mixing signal of RF beam during a 105 GHz/300 kW/2 s long-pulse operation

    表  1  105/140 GHz MW回旋管设计参数

    Table  1.   Design parameters of the 105/140 GHz MW gyrotron

    No.parametervalue
    1
    2
    3
    output power
    pulse width
    total beam voltage
    1.0 MW
    continuous wave
    −81 kV
    4beam current40 A
    5MIGtriode type
    6cavity modeTE18,7@105 GHz; TE24,9@139.3 GHz
    7working magnetic field4.1 T@105 GHz; 5.5 T@140 GHz
    8output modequasi-Gaussian beam
    9windowBN disk for short-pulse operation; CVD diamond for MW-level CW operation
    10collectorsingle-stage depressed collector (SDC)
    11efficiency>30% (45% with SDC)
    下载: 导出CSV
  • [1] Nusinovich G S, Thumm M K A, Petelin M I. The gyrotron at 50: historical overview[J]. Journal of Infrared, Millimeter, and Terahertz Waves, 2014, 35(4): 325-381. doi: 10.1007/s10762-014-0050-7
    [2] Thumm M K A, Denisov G G, Sakamoto K, et al. High-power gyrotrons for electron cyclotron heating and current drive[J]. Nuclear Fusion, 2019, 59: 073001. doi: 10.1088/1741-4326/ab2005
    [3] Kariya T, Imai T, Minami R, et al. Development of over-MW gyrotrons for fusion at 14 GHz to sub-THz frequencies[J]. Nuclear Fusion, 2017, 57: 066001. doi: 10.1088/1741-4326/aa6875
    [4] Ikeda R, Kajiwara K, Nakai T, et al. Progress on performance tests of ITER gyrotrons and design of dual-frequency gyrotrons for ITER staged operation plan[J]. Nuclear Fusion, 2021, 61: 106031. doi: 10.1088/1741-4326/ac21f7
    [5] Hu Linlin, Sun Dimin, Huang Qili, et al. Design and preliminary test of a 105/140 GHz dual-frequency MW-level gyrotron[J]. Plasma Science and Technology, 2022, 24: 035601. doi: 10.1088/2058-6272/ac2b8f
    [6] Hu Linlin, Ma Guowu, Sun Dimin, et al. Development of a 28-GHz/50-kW/30-s gyrotron system for fusion application[J]. IEEE Transactions on Plasma Science, 2021, 49(4): 1468-1474. doi: 10.1109/TPS.2021.3066553
    [7] 胡林林, 马国武, 孙迪敏, 等. 28 GHz/50 kW准光输出连续波回旋管[J]. 强激光与粒子束, 2019, 31:060101 doi: 10.11884/HPLPB201931.190139

    Hu Linlin, Ma Guowu, Sun Dimin, et al. A 28 GHz/50 kW continuous wave gyrotron with quasi-optical output[J]. High Power Laser and Particle Beams, 2019, 31: 060101 doi: 10.11884/HPLPB201931.190139
    [8] Sun Dimin, Ma Guowu, Huang Qili, et al. Recent results of 28 GHz 400 kW long pulse gyrotrons at IAE-CAEP[C]//2021 46th International Conference on Infrared, Millimeter and Terahertz Waves (IRMMW-THz). 2021: 1-2.
    [9] 胡林林, 孙迪敏, 黄麒力, 等. 105/140GHz双频兆瓦回旋管实现1.0MW脉冲输出[J]. 强激光与粒子束, 2023, 35:023001 doi: 10.11884/HPLPB202335.220388

    Hu Linlin, Sun Dimin, Huang Qili, et al. 1.0 MW pulse power achieved in 105/140 GHz dual-frequency MW-level gyrotron[J]. High Power Laser and Particle Beams, 2023, 35: 023001 doi: 10.11884/HPLPB202335.220388
    [10] 黄麒力, 孙迪敏, 马国武, 等. 双频回旋管内置准光模式变换器设计[J]. 强激光与粒子束, 2020, 32:053001 doi: 10.11884/HPLPB202032.190446

    Huang Qili, Sun Dimin, Ma Guowu, et al. Design of quasi-optical mode converter for dual-frequency gyrotron[J]. High Power Laser and Particle Beams, 2020, 32: 053001 doi: 10.11884/HPLPB202032.190446
    [11] 黄麒力, 胡林林, 马国武, 等. 基于量热法的大功率毫米波功率测量及校准系统设计[J]. 强激光与粒子束, 2022, 34:043005 doi: 10.11884/HPLPB202234.210501

    Huang Qili, Hu Linlin, Ma Guowu, et al. Design of high power millimeter wave power measurement and calibration system based on calorimetry[J]. High Power Laser and Particle Beams, 2022, 34: 043005 doi: 10.11884/HPLPB202234.210501
