回旋振荡管收集极横向磁扫描系统的设计与仿真

李晗; 杨晨; 罗积润; 樊宇; 朱敏; 郭炜

doi:10.11884/HPLPB202133.210053

回旋振荡管收集极横向磁扫描系统的设计与仿真

doi: 10.11884/HPLPB202133.210053

李晗^{1, 2,},
杨晨^{1, 2},
罗积润^{1, 2},
樊宇¹,
朱敏¹,
郭炜¹

1.
中国科学院空天信息创新研究院高功率微波源技术科学与技术重点实验室，北京 100190
2.
中国科学院大学电子电气与通信工程学院，北京 100049

基金项目: 国家高技术发展计划项目（Y8BD140353）

详细信息

作者简介:
李　晗（1995—），女，硕士研究生，从事激光应用及新型光器件研究

中图分类号: TN129
计量
- 文章访问数: 730
- HTML全文浏览量: 324
- PDF下载量: 29
- 被引次数: 0
出版历程
- 收稿日期: 2021-02-22
- 修回日期: 2021-06-02
- 网络出版日期: 2021-06-28
- 刊出日期: 2021-07-15

Design and simulation of the transverse magnetic scanning system of gyrotron oscillator collector

Li Han^{1, 2
,},
Yang Chen^{1, 2},
Luo Jirun^{1, 2},
Fan Yu¹,
Zhu Min¹,
Guo Wei¹

1.
The Key Laboratory of Science and Technology on High Power Microwave Sources and Technologies, Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100190, China
2.
School of Electronic, Electrical and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 从降低收集极表面峰值功率和平均功率入手，设计了一种由12个横向椭圆交流线圈和2个轴向直流线圈组成的磁场扫描系统。针对140 GHz、TE_28,8模、1 MW功率输出回旋振荡管收集极的设计参数，结合电磁场理论和带电粒子电磁软件仿真，获得收集极表面上电子注的峰值和平均功率密度分别不超过404.91 W/cm²和244.01 W/cm²，以及扫描长度达到443.33 mm的扫描效果，有效地缓解了收集极功率耗散和冷却的压力。
- 回旋振荡管 /
- 收集极 /
- 横向磁场扫描 /
- 椭圆线圈 /
- 功率密度
Abstract: Starting from reducing the peak power and average power on the collector surface of a gyrotron oscillator, we have designed a magnetic field scanning system composed of 12 transverse elliptical AC coils and 2 longitudinal DC coils. According to the design parameters of the collector electrode of 140 GHz, TE_{28, 8} mode, 1 MW gyrotron oscillator, and combining electromagnetic field theory with particle-in-cell (PIC) simulation program, the scanning system can realize that the peak and average power density of the electron beam on the collector surface are not more than 404.91 W/cm² and 244.01 W/cm² respectively with a scanning length of 443.33 mm, which effectively alleviates the pressure of power dissipation and cooling of the collector.
- gyrotron oscillator /
- collector /
- transverse magnetic field scanning /
- elliptical coil /
- power density

HTML全文

图 1 TFSS结构示意图

Figure 1. Schematic diagram of TFSS structure

下载: 全尺寸图片幻灯片

图 2 TFSS对电子注轨迹的影响

Figure 2. Influence of TF_coils on electron beam trajectory

下载: 全尺寸图片幻灯片

图 3 TFSS电流幅度对电子注落点的影响

Figure 3. Influence of TFSS current amplitude on electron beam trajectory

下载: 全尺寸图片幻灯片

图 4 VF_coil与TF_coils对于电子注空间分布的影响

Figure 4. Influence of VF_coil and TF_coils on the spatial distribution of electron Beams

下载: 全尺寸图片幻灯片

图 5 加载VF_coil、TF_coils时收集极上轴向的功率密度分布

Figure 5. The axial power density distribution of the collector when VF_coil and TF_coils are loaded

下载: 全尺寸图片幻灯片

图 6 12个椭圆线圈构成的TF_coils相位分布

Figure 6. Phase distribution of TF_coils composed of 12 elliptical coils

下载: 全尺寸图片幻灯片

图 7 TFSS中VF_coils的个数增加时的电子注空间分布

Figure 7. The electron beam spatial distribution on the collector surface for different number of VF_coils

下载: 全尺寸图片幻灯片

图 8 调整后的TFSS模型与功率密度分布

Figure 8. Adjusted TFSS model and power density distribution

下载: 全尺寸图片幻灯片

图 9 优化后的TFSS模型结构示意图

Figure 9. Schematic diagram of optimized TFSS model structure

下载: 全尺寸图片幻灯片

表 1 回旋管部分参数

Table 1. Parameters of gyrotron

anode voltage U₀ /kV	modulated anode voltage U_m/kV	current I₀ /A	electron injection efficiency η_e/%
81	54	40	35

下载: 导出CSV

表 2 不同情况下收集极上电子注的分布参数

Table 2. Electron beam parameters on the collector surface under different conditions

coils loaded on the collector	peak power density/ (W/cm²）	mean power density/ (W/cm²）	vertical scan length/ mm
non-coil	3523.40	1820.92	58.74
1VF_coil	2803.23	1363.46	78.45
6TF_coils	679.51	318.23	336.10
6TF_coils &1VF_coil	574.81	271.86	393.43

下载: 导出CSV

表 3 电子注分布参数对比

Table 3. Comparison of electronic beam distribution parameters

coils loaded on the collector	peak power density/（W/cm²）	mean power density/（W/cm²）	vertical scan length/mm
6TF_coils &1VF_coil	574.81	271.86	393.43
12TF_coil &1VF_coil	688.24	353.49	303.33

下载: 导出CSV

表 4 轴向扫描线圈个数不同时收集极上电子注的分布参数

Table 4. The electron beam distribution parameters on the collector surface for different number of VF_coils

coils loaded on the collector	peak power density/（W/cm²）	mean power density/（W/cm²）	vertical scan length/mm
12TF_coil &1VF_coil	688.24	353.49	303.33
12TF_coils &2VF_coils	472.99	272.29	396.67
12TF_coils &3VF_coils	633.75	327.55	326.67
12TF_coils &4VF_coils	547.14	288.69	373.33

下载: 导出CSV

表 5 图8（b）中三种情况对应的收集极上轴向功率密度的分布参数

Table 5. The distribution parameters of the axial power density on the collector corresponding to the three cases in Figure 8(b)

（Z_min_TFSS，Z_max_TFSS）	peak power density/（W/cm²）	mean power density/（W/cm²）	vertical scan length/mm
（710，1545）	426.52	251.17	431.67
（720，1555）	404.91	244.01	443.33
（730，1565）	477.18	238.26	455.00

下载: 导出CSV

表 6 与现有方案的参数对比

Table 6. Comparison of parameters with existing schemes

	frequency/ GHz	dissipated power /MW	peak power density/（W/cm²）	vertical scan length/mm	ampere turns of TF_coils/（kA·T）	ampere turns of VF_coils/（kA·T）	number of coils（TF，VF）
ref.[12]	W-band	0.5-1	130	480 mm	1.554（6A×259T）	0.81（5A×162T）	（6，1）
ref.[13]	140	0.1	450	−	7	0	（6，1）
ref.[14]	140	1	−	330 mm	7.9	1	（6，1）
ref.[15]	140	1	370	380 mm	−	−	（6，1）
ref.[16]	170	1	288.66	−	4	10	（6，1）
this paper	140	1.2	404.91	443.33	2.4	1.56	（12，2）

下载: 导出CSV

表 7 TFSS仿真模型关键参数

Table 7. Key parameters of TFSS simulation model

type of coils	outer radius（mm）	thickness/mm	length/mm	ampere turns of single coil /（kA·turn）	number of coils	distance from coils’ center to origin/mm
TF_coils	160（SMA） 70（SMI）	30	50	2.4（6A×400T）	12	880
VF_coils	220	10	240	1.56（5.2A×300T）	2	1320

下载: 导出CSV
